MAN TGM – Specifications
Specifications
+−Chassis
| Chassis | Tipper | |
|---|---|---|
| 4x2 | X | X |
| 4x4 | X | X |
| 6x2- | X | _ |
| 6x2 | _ | _ |
| 6x4 | _ | X |
| 6x4- | _ | _ |
| 6x6 | _ | _ |
| 8x2- | _ | _ |
| 8x4 | _ | _ |
| 8x4/ 8x4- | _ | _ |
| 8x6 / 8x8 | _ | _ |
+−Engine & Performance Data
| Engine series | Cylinder, design | Displacement [Liter] | Performance [kW (PS)] | Emission standard | For vehicle series |
|---|---|---|---|---|---|
| D0836 | 6 in-line | 6.9 | 235 (320) / 213 (290) / 184 (250) | Euro 5 | TGM |
+−Cabs
CC cab (the compact: slim, short, medium high) — external length 1,620 mm, external width 2,240 mm, interior length 1,550 mm, interior width 2,070 mm, 2 (optionally 3) seats.
DN cab (the double cabin) — external length 2,790 mm, external width 2,240 mm, interior length 2,650 mm, interior width 2,070 mm, 6 (optionally 7) seats.
TN cab (the flexible: slim, long, standard height) — external length 2,280 mm, external width 2,240 mm, interior length 2,145 mm, interior width 2,070 mm, 2 seats, 208 l left + 242 l right rear storage boxes, 133 l central storage below bed.
All three cabs are qualified to very good for standard long-haul, distribution, construction-site traction and municipal applications.
+−Media Systems
Available in five tiers: MAN media system Navigation Professional (12.3"), Navigation Advanced (7"), Advanced (7"), the base 7" media system, and the MAN radio with SD card (7").
USB/AUX input, MAN SmartSelect compatibility, and a message centre are standard from the base 7" tier upward. Truck navigation, map updates and online traffic are exclusive to the two Navigation tiers. Comfort hands-free calling for two phones is available on the two Navigation tiers; basic hands-free is available on Advanced and the base tier. Bluetooth streaming and an SD card reader are standard across all tiers; smartphone integration is available from the base tier upward.
